Welcome To Technical Specialists

CB Radio Repair Books

Cobra 25 Repair for Truck Drivers

A step-by-step guide to repairing all common failures that occur in a Cobra 25 CB Radio.

Has diagrams, alignment and parts lists.



Cobra 29 Repair for Truck Drivers

A step-by-step guide to repairing all common failures that occur in a Cobra 29 CB Radio.

Has diagrams, alignment and parts lists.





Replacements for Discontinued Finals

Many 2-way radios were made with bipolar transistors that have been

discontinued. This includes many of the popular cb radios. There are still

lots of these transistors stockpiled in various places, but the supply is

diminishing. Many CB radios use a 2SC1969, 2SC2078, 2SC2312 and 2SC2166

as the final. These transistors have not been made in over 2 years. A suitable

replacement had to be found. there are a number of other transistors that

will work in that circuit with a few changes to the circuit. We have a MOSFET

device made by International Rectifier that requires very little modification

 to the circuit and produces far more output. One nice advantage to the

mosfet is that with a little more DC voltage applied to the unit - even more

power is produced. At near 15volts it produces about 40 watts or even more.

Below 14volts not much power increase is obtained. There is, however,

a large increase in modulation. Most autos provide 14.4 - 14.8vdc while

the engine is running. The kits listed below have all

the required parts and instructions on how to install them.

Some soldering is required.

If you are looking for our fix it yourself books - use the "Books" link at the left or the link

at the bottom to go to our store.

Near Real Time Solar Data





Repair Kits

We have kits to repair specific problems in the most popular models.

Click here





Final Transistor Mod for Cobra 25 $18 + $8 sh



Final Transistor Mod for Cobra 29 $18 + $8 sh



Final Transistor Mod for Uniden 66,68 $18 + $8 sh



Final Transistor Mod for Uniden 76,78 $18 + $8 sh



Final Transistor Mod for Galaxy 33,44,55,66,73 $26



Final Transistor Mod for Galaxy 77,88,99 $34



Final Transistor Mod for Connex (single final) $26



Final Transistor Mod for Connex HP models $34

Final Transistor Mod for Ranger (single final) $26

(not available at this time)

Final Transistor Mod for Ranger (dual final) $34



Final Transistor Mod for Magnum (Note: The newer version of the Magnum

radio already has a mosfet device <ERF-2030 or IRF-520> installed)  $34



Final Transistor Mod for Northstar (single final)  $26



Final Transistor Mod for Northstar (dual final) $34



Final Transistor Mod for Texas Ranger (single final) $26



Final Transistor Mod for Texas Ranger (dual final) $34



Go to next page



Want to see more kits?
